Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
9-18
Using the Print Left of Form Option
Follow this instruction.
Step Procedure
1 Use the edge alignment grid (located at the top center of the card) to:
• Adjust the Print LOF up or down by the number (located below the line
located closest to the edge of the card).
2 a. Measure the density square, as shown below.
b. Adjust the image density to 66% ± 1%.

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
