Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
8-97
Defining the Area to activate the Card Grid
Step Procedure
1 Select on the appropriate Defined Area (see below) to activate the card grid
in the upper half of the window.
• It is through this card grid that up to five areas can be defined, as shown
below.
• When the card grid is first activated, then a small black square will
appear at its default size of .2 x .2 (5mm x 5mm) and at its default
location in the lower left-hand corner (0,0). (Note: This square
represents the first defined area.)

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
