Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
6-35
Specifying TCP Event logging
Follow this procedure to send logging messages to a pre-existing IP connection made on the
TCP port.
Step Procedure
1 Select the System Log link.
2 Select the link for the log name you want to view or configure (the default
choices are log1 or log2).
3 Select the TCP Connection radio button.
4 Select Submit.
5 Login as a root User if you are so prompted. Any change of setting will only be
accepted after you have successfully logged in.

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
