Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
8-83
Selecting the Lamination Position
Step Procedure
1 Use the Lamination Position control to adjust the horizontal position of
the PolyGuard Overlaminate. (Note: This control functions in the same
manner as the Image Position controls, except only the horizontal position
of the overlaminate requires adjustment.)
• To adjust the Lamination position, click on the Horizontal adjustment
arrows.
• To move the overlaminate more toward the card output side of the
Printer, enter a positive number.
• To move the overlaminate more toward the card input side of the
Printer, enter a negative number. (Note: The adjustment arrows point
in the direction the patch will move on the card. The maximum value for
the Horizontal adjustment is ±100 Pixels (10 Pixels = about .03/.8mm)
The default is 0.)

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
