Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
8-66
Selecting the Coercivity/Magnetic Track
Use the ISO option for encoding capability for either high- or low-coercivity cards on tracks 1,
2 and 3 and is the industry's standard mode of magnetic encoding.
Step Procedure
1 Select the Coercivity option (Oersted) to use the Magnetic Stripe type that
matches the card type.
• High Coercivity to Super Coercivity = 2750-4000 Oersted (Fargo’s High
Coercivity UltraCard IIIs are 2750 Oe)
• Medium Coercivity = 600 Oersted
• Low Coercivity = 300 Oersted
2 Select the Magnetic Track Selection option to specify which track is to be
configured through the Magnetic Track Options (if the application being used
requires customization of the standard ISO encoding process). See
Reviewing the Magnetic Track Options
.

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
