Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
8-53
Adjusting the Image Position controls
Use the Image Position controls to position the image on a card (to be adjusted).
Step Procedure
1 Adjust the Image Position values by clicking on the Vertical and Horizontal
adjustment arrows.
• These values ensure that the Cards always remain in the same position
as they travel through the Printer (regardless of image orientation).
• The Card Illustration (shown in the Image Position box) will flip and rotate
according to the selection of Portrait, Landscape or Rotate 180 Degrees.
• The outline around the illustration will always remain in the same
Landscape orientation.

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
