RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
2-18
Printer Components: LCD and Softkey Control Pad
The Printer provides a two line, thirty-two (32) character LCD Display that can communicate
helpful information about the Printer's operation. The bottom line of the LCD Display will
always be used to communicate the current function of the Printer's softkey buttons.
This section describes how the LCD Display and Softkey Control Pad work together.
Component Description
Softkey
Buttons
The Printer has two softkey buttons that appear below the LCD
Display. Their current function is indicated by the words appearing
above them. This function will change according to the Printer's current
mode of operation.
• Press the corresponding softkey button under the choice you want
to select. If no word appears above a particular button, this
indicates it has no function in that particular mode of operation.
LCD Display The Printer's LCD Display will change according to the Printer's current
mode of operation.
Ready /
Printer Open
Screens
Once the Printer has finished its system check and with the Printer
closed, the Printer will display Printer Ready to indicate that the Printer
is ready for operation. (Note: The Printer will stay in this mode until it
receives a print job or it is turned OFF.)
• If the Printer is opened, the Cover is Open screen will appear.
Press either the Forward or Back buttons to move the Printer's
card path Rollers in the indicated direction. (Note: This is helpful
when cleaning the Printer or if clearing jammed media.)
• All rollers will move even if the Lam cover is not opened.
