Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
9-10
Selecting the Clean Printer tab
The button for the Clean Printer tab is described below.
• Clean Button: Launches cleaning routine. Follow the instruction on the page for setting
up the Printer.
• Help button: Launches help that is specific to this tab.
Step Procedure
1 Click the Clean Printer tab. See the next page.
a. Remove the Card, Film and Laminate Cartridges and close the covers.
b. Remove the paper back from both sides of the Cleaning Card. (Note:
DO NOT remove the left liner if a Magnetic Encoding Module is installed
in your printer.)
c. Insert the Cleaning Card into the Card Hopper’s Infeed Rollers.
d. Click on the Clean button below.
e. Guide the Cleaning Card into the Printer as needed.
f. When the Cleaning routine is complete, the Cleaning Card will exit the
Printer.
g. Reinstall the Card, Film and Laminate Cartridges.
The Cleaning routine will begin after all current print jobs have completed.
Continued on the next page

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
