Fargo HDP5000 - Quality - Color Matching (Resin Heat)

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
8-42
Using the Quality – Color Matching dropdown (continued)
Step Procedure
3 Control the amount of heat the Printer uses when printing with the resin black
Panel by adjusting the Resin Heat slide.
• Move the slide to the left to cause less heat to be used in the printing
process, causing resin images to be lighter or less saturated.
OR
• Move the slide to the right to cause more heat to be used, causing resin
images to be darker or more saturated.
(Note: This control can be helpful for fine-tuning the sharpness of resin text
and bar codes.)
