RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
2-13
Technical Specifications (continued)
Term Description
Print Ribbon
Options
HDP5000 and HDP5000-LC (prints or images):
• Full color, YMC*, 750 prints
• Full color with resin black, YMCK*, 500 prints
• Full color with two resin black Panels, YMCKK*, 500 prints
• Full color YMC with resin black and heat seal panel for difficult-
to-print surfaces, YMCKH*, 500 prints
• Full color YMC with resin black and UV fluorescing panel,
YMCFK*, 500 prints
*Indicates the Ribbon type and the number of Ribbon panels printed
where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black, H=Heat
Seal and F=Fluorescing
Print Speed-
Batch Mode
HDP5000 and HDP5000-LC (see note below):
• 38 seconds per card / 95 cards per hour (YMC with transfer)*
• 46 seconds per card / 78 cards per hour (YMCK with transfer)*
• 70 seconds per card / 51 cards per hour (YMCKK with
transfer)*
• 70 seconds per card / 51 cards per hour (YMCFK with
transfer)*
• 50 seconds per card / 72 cards per hour (YMCK with transfer
and dual-sided, simultaneous lamination)*
• 75 seconds per card / 48 cards per hour (YMCKK with transfer
and dual-sided, simultaneous lamination)*
Print speed indicates an approximate print speed and is measured
from the time a card feeds into the Printer to the time it ejects from
the Printer.
• Print speeds do not include encoding time or the time needed
for the PC to process the image.
• Process time is dependent on the size of the file, the CPU,
amount of RAM and the amount of available resources at the
time of the print.
Resolution 300 dpi (11.8 dots/mm)
