178
Relay
S
Stepping Relay
1
DDDD
0
2047
T
Timer
1
DDDD
0
2047
TV
Timer memory
16
DDDD
0
2047
C
Counter
1
DDDD
0
2047
CV
Counter memory
16
DDDD
0
2047
HC
32-bit Counter
1
DD
0
63
HCV
32-bit Counter
memory
32
DD
0
63
SR
Special data register
16
DDDD
0
2047
E
Index register
16
DD
0
31
2.9.2.3 Connecting to HMI
Configuring the PLC
Use the application ISPSoft (Ver. 2.05) to configure the PLC. The application COMMGR
is used to establish the connection between the PLC and the computer.
Open COMMGR. The application opens in the system tray. Double click the icon to
open it.
In Device Manager, verify the port number the PLC is connected to. In COMMGR, press
Add and for Connection Setup, select RS232/422/485 for type. Select the port number
the PLC is connected to for the COM Port setting. Press Auto-detect and the
application will automatically adjust the rest of the parameters.
