2.12.2.2 Memory Resource Review
Device
Description
Data
bit
Input
format
Min.
Max.
R
Relay
1
DDDdd
0
99915
B
Link relay
1
HHHH
0
7FFF
MR
Internal auxiliary
relay
1
DDDDdd
0
399915
LR
Latch relay
1
DDDdd
0
99915
T
Timer
1
DDDD
0
3999
C
Counter
1
DDDD
0
3999
CTC_sts
High-speed counter
comparator
(contact)
1
D
0
7
CR
Control relay
1
DDdd
0
7915
VB
Work relay
1
HHHH
0
F9FF
DM
Data memory
16
DDDDD
0
65534
EM
Extended data
memory
16
DDDDD
0
65534
FM
File register
16
DDDDD
0
32767
ZF
File register
16
DDDDDD
0
524287
W
Link register
16
HHHH
0
7FFFF
TM
Temporary data
memory
16
DDD
0
511
CM
Control memory
16
DDDD
0
5999
VM
Work memory
16
DDDDD
0
50999
Z
Index register
32
D
1
12
TC
Timer (current
value)
32
DDDD
0
3999
TS
Timer (set value)
32
DDDD
0
3999
CC
Counter (current
value)
32
DDDD
0
3999
CS
Counter (set value)
32
DDDD
0
3999
CTH
High-speed counter
(current value)
32
D
0
3
CTC
High-speed counter
comparator (set
32
D
0
7
