Fazzini FM5000C User Manual

17-4
FM5000C - FM5000PLUS
Maternal/Fetal Monitor
User Manual
Y-type SpO2sensor
SpO2sensor jacket
Figure17-3NeonatalSpO2sensor (1)
Figure17-4NeonatalSpO2sensor (2)
Attach the sensor to the neonatal hand or foot as shown below.
Figure17-5Placement of the neonatal SpO2sensor
Attention
 When the accurate positioning between the test site and the probe fails, it may result
in wrong readings of SpO2, and even stop monitoring because of the failure of searching pulse.
In this case you should re-position these two.
 Excessive movement of measured sites may affect the accuracy of the measurement,
therefore, you should calm the patient or replace sites in order to reduce the impact of
excessive movement.
Warning
 The maximum measuring time of SpO2 sensor on a single measuring site is 2 hours.
 In a long and continuous monitoring process, it is advisable to check periodically the
positioning of the sensor to avoid inaccurate measurement due to changing in the positioning
because of moving or other factors.
