II-5

FM5000C - FM5000PLUS

Maternal/Fetal Monitor

User Manual

Baseline control and

stability

Reset time

Drift rate in 10s

10µV/s

Baseline drift in 1h

≤500µV

Baseline drift under working temperature

≤50µV/℃

Pulse inhibition of

Amplitude: ±2mV~±700mV; width: 0.1ms~2.0ms (method A).
