(8) Respiration
Name
Specification
Method
Thoracic impedance method
Measurement
range and
accuracy
Range
Adult
6～120 rpm
Pediatric/neonate
6～150 rpm
Accuracy
7rpm～150rpm: ±1rpm or 1%, whichever is the larger;
0rpm～6rpm：Not specified
Alarm range and
accuracy
Adult
7rpm～120rpm
Pediatric/ neonate
7rpm～150rpm
Accuracy
±1bpm
Apnea alarm time
10s, 15s, 20s, 25s, 30s, 35s, 40s,error: ±5s.
(9) NIBP
Name
Specification
Measuring method
Oscillation method
Measurement
range and accuracy
Adult
Systolic pressure
40mmHg～270mmHg(5.3kPa～36.0kPa)
Mean arterial pressure
20mmHg～235mmHg(2.7kPa～31.3kPa)
Diastolic pressure
10mmHg～215mmHg(1.3kPa～28.7kPa)
Pediatric
Systolic pressure
40mmHg～200mmHg(5.3kPa～26.7kPa)
Mean arterial pressure
20mmHg～165mmHg(2.7kPa～22.0kPa)
Diastolic pressure
10mmHg～150mmHg(1.3kPa～20.0kPa)
Neonate
Systolic pressure
40mmHg～135mmHg(5.3kPa～18.0kPa)
Mean arterial pressure
20mmHg～110mmHg(2.7kPa～14.7kPa)
Diastolic pressure
10mmHg～100mmHg(1.3kPa～13.3kPa)
Accuracy
The maximum mean deviation is ±5mmHg(±0.667kPa) and the
maximum standard deviation is 8mmHg(±1.067kPa).
Overpressure
protection
Adult
300mmHg
Pediatric
240mmHg
Neonate
150mmHg
Error
±3mmHg
Static pressure
measurement
range
0mmHg~300mmHg,
Accuracy
±3mmHg
Alarm range and
accuracy
Adult
Systolic pressure:
40mmHg～270mmHg(5.3kPa～36.0kPa)
Mean arterial pressure:
20mmHg～235mmHg(2.7kPa～31.3kPa)
Diastolic pressure
10mmHg～215mmHg(1.3kPa～28.7kPa)
Pediatric
Systolic pressure:
40mmHg～200mmHg(5.3kPa～26.7kPa)
