FENDT 926 Vario User Manual

249
TECHNICAL DATA
Model 924 926 930
Engine
Engine type DO836LE506 DO836LE505 DO836LE510
Turbocharger / intercooler with / with with / with with / with
No. of cylinders / cooling 6 / water 6 / water 6 / water
Bore / stroke mm 108 / 125 108 / 125 108 / 125
Effective displacement l 6,870 6,870 6,870
Idling speed rpm 810 ±30 810 ±30 810 ±30
Rated speed rpm 2250 2250 2250
Engine speed without load rpm 2510-2550 2510-2550 2510-2550
Fuel l 530 530 530
Engine switch-off electrical electrical electrical
Noise level at driver's ear dB(A) 72 72 72
Engine alignment
Ensure vehicle stability
Lengthwise in travel direction high / low degree 25 25 25
Across travel direction left / right degree 25 25 25
Dimensions and weights
with the following tyres and track width
Tyres front 540/65 R34 600/65 R34 600/65 R34
Tyres rear 650/65R42 650/85R38 710/70R42
Track width front mm 2000 2000 2000
Track width, rear mm 1970 1970 1970
Overall length mm 4940 4940 4940
Overall width mm 2580 2640 2700
Total height mm 3110 3110 3110
Ground clearance mm 605 605 605
Wheelbase mm 2840 2840 2840
Flange size front mm 1892 1892 1892
Flange size rear mm 1890 1890 1890
Min. track circle radius without / with steering
clutch brake mm 5,9/5,4 5,9/5,4 5,9/5,4
Unloaded weight kg 8800 8800 8950
Max. permissible gross weight 50 km/h kg 12000 12000 12000
Max. permissible gross weight with implement,
depending on tyres kg 14000 14000 14000
Max. permissible front axle load kg 5450 6000 6000
Max. permissible rear axle load kg 8500 8500 9500
Max. vertical bearing load on trailer hitch kg 2000 2000 2000
Permissible vertical bearing load on trailer
hitch
kg 3000 3000 3000
Rear PTOs 540/540E/1000
PTO shaft profile 1 3/4 6-part 1 3/4 6-part 1 3/4 6-part
PTO speed at rated engine speed and 540 set-
ting rpm 596 596 596
PTO speed at rated engine speed and 540E
setting rpm 760 760 760
PTO speed at rated speed and 1000 setting rpm 1108 1108 1108
PTO speed at rated engine speed in setting
750 Nm 3500 3500 3500
Max. permissible torque for 540E setting Nm 2100 2100 2100
PTO speed when rated engine speed is selec-
ted for 1000 Nm 1600 1600 1600
Front PTO 1000
PTO speed at nominal speed 1000 version rpm 1111 1111 1111
PTO speed when rated engine speed is selec-
ted for 1000 Nm 830 830 830

FENDT 926 Vario Specifications

General

Engine Power	260 hp
Transmission	Vario continuously variable transmission
Fuel Tank Capacity	500 liters
Weight	10, 500 kg
Engine type	6-cylinder turbocharged
Rated engine speed	2100 rpm
Displacement	7.5 liters
Number of cylinders	6
Maximum speed	50 km/h
Tire Options	Multiple options available
