FENDT 926 Vario User Manual

250
TECHNICAL DATA
Text-module
NOTE:
Any modifications to the power output limiter and max. speed setting shall render the Warranty
invalid. This also applies to any exceeding of the maximum permissible loads and weights.
NOTE:
For PTO mode:
If the maximum permissible torque can be exceeded (depending on the application), use a drive
shaft with safety coupling and overrunning clutch if necessary.
Maximum failsafe mechanism to prevent blocking at peaks in torque of 4000 Nm.
Hydraulics
Working pressure bar 200 200 200
Hydraulic pump l 117 117 117
Hydr. oil extraction flow at max. capacity l 65 65 65
Rear power lift
Three-point cat. 2/3 cat. 2/3 cat. 2/3
Control EPC EPC EPC
Maximum lifting power at drawbar kN 108,5 108,5 108,5
Front power lift (optional)
Three-point Cat. 2 Cat. 2 Cat. 2
Max. lifting power kN 50,0 50,0 50,0
Weight of implement at coupling point kg 3600 3600 3600
Transmission
Continuously variable Vario transmission km/h 50 50 50
Range I forwards km/h 0,02 - 32 0,02 - 32 0,02 - 32
Driving mode I reverse km/h 0,02 - 20 0,02 - 20 0,02 - 20
Driving mode II forwards km/h 0,02 - 50 0,02 - 50 0,02 - 50
Driving mode II reverse km/h 0,02 - 38 0,02 - 38 0,02 - 38
Electrical system
Operating tension V 12 12 12
Battery V/Ah 2x 12/90 2x 12/90 2x 12/90
Alternator W/V/A 2520/14/2x90 2520/14/2x90 2520/14/2x90
Starter kW 4,0 4,0 4,0
Tightening torques for wheels (threads and
contact surfaces lightly oiled)
Front wheels Nm 450 450 450
Rear wheels Nm 620 620 620
Model 924 926 930

FENDT 926 Vario Specifications

General

Engine Power	260 hp
Transmission	Vario continuously variable transmission
Fuel Tank Capacity	500 liters
Weight	10, 500 kg
Engine type	6-cylinder turbocharged
Rated engine speed	2100 rpm
Displacement	7.5 liters
Number of cylinders	6
Maximum speed	50 km/h
Tire Options	Multiple options available
