61
OPERATION
14.2 PTO automatic mode
Allows the control of rear and front PTOs to be
transferred to the buttons on the joystick.
Activating the automatic function
Operation_Pic_number:1
● Selecting PTO speed for rear PTO, (see
OPERATION Section 10.1).
NOTE:
The automatic function can be deselected at
any time.
Button (J), rear PTO automatic mode
ON/OFF.
Button (Q), front PTO automatic mode
ON/OFF.
Fig.104
Using automatic mode
Operation_Pic_number:1
Text-module
● Button (A1), front PTO ON.
● Button (A2), front PTO OFF.
● Toggle switch to (B1), rear PTO ON.
● Toggle switch to (B2), rear PTO OFF.
● Stop button (C), PTOs (front and rear) are
both disengaged.
Text-module
NOTE:
The PTO automatic mode can be activated
with PTOs engaged or disengaged.
Fig.105
