113
Rev. 5.1
ZMT-ZMTE
OPTIONAL UNITS
12.6
12-Kit idraulico di sicurezza (ZMT-ZMTE)
1
A
12.3 Hydraulicsafetydevicekit
If during work the machine comes into contact with a strong body, the shredder moves automatically by means of a
maximum pressure valve (1) connected to the hydraulic jack (A), to prevent serious damage to the structure of the
machine.
This system allows the booms to be retracted to absorb the shock and gives the operator the necessary time to carry
out the manoeuvres to get past the obstacle.
Once the obstacle has been overcome, it is necessary to reset the working position of the shredder, using the hydraulic
jack control lever which activates lateral movement.
When approaching obstacles, advance very slowly because the space to move back in
is limited.
When retracting the booms, do not go beyond an angle of 10°, to avoid stressing
anomalously the frame structure and booms.
With the booms fully extended proceed with greater caution as the obstacle asorption
capacity is more limited.
CAUTION
