35
Rev. 5.1
ZMT-ZMTE
TECHNICAL CHARACTERISTICS
3.3
03-Dati tecnici (ZMT-ZMTE)
E
D
B
A
C
ZMT1600 ZMT1800 ZMT2000
A
m
1,64 1,84 2,04
ft
5’ 5” 6’ 1” 6’ 8”
B
m
0,89 0,92 0,92
ft
2’ 11-1/20” 3’ 0-1/10” 3’ 0-1/10”
C
m
0,43 0,46 0,46
ft
1’ 5-1/20” 1’ 6-3/10” 1’ 6-3/10”
D
m
0,65 0,71 0,71
ft
2’ 1-3/4” 2’ 3-19/20” 2’ 3-19/20”
E
m
1,75 1,98 2,18
ft
5’ 9” 6’ 6” 7’ 2”
3.4 Technical Data (ZMT)
TAB 1
Model ZMT1600 ZMT1800 ZMT2000
Working width cm (in) 160 (63) 180 (71) 200 (79)
Max. lateral extension (*) cm (in) 222 (87) 242 (95) 262 (103)
Minimum/maximum tractor power HP (KW) 50/60 (36,8/44,1) 60/70 (44,1/51,5) 70/80 (51,5/58,9)
Min. tractor width cm (in) 180 (71) 200 (79) 220 (87)
Minimum tractor weight Kg (lbs) 2200 (4850) 2400 (5291) 2600 (5732)
PTO speed rpm 540
Max. absorbed power (**) HP (KW) 32 (23) 52 (38) 52 (38)
Machine weight/Shaft weight Kg (lbs) 511/25 (1126/55,1) 588/25 (1296/55,1) 614/25 (1353/55,1)
Tractor coupling cat. II-III
Rotor speed rpm 2430 2510 2510
Peripheral speed m/sec 46 50 50
Multi-use ails No. 40 48 48
Hammers No. 20 24 24
Articulated ails No. 56 64 72
Hydraulic system pressure Bar (PSI) 190 (2750)
Hydraulic oil type ISO-L-HM68
Belts No. 3 3 4
Max. inclination of shredding body degrees (low) 45° (high) 90°
(*) From the tractor axle to the end of the shredding ail head
(**) For work in which the absorption is above the maximum power indicated, use a PTO shaft with a clutch (torque
limiting device).
The tractor must be equipped with 2 double eect oil inlets.
If only one oil inlet is available, it will be necessary to t a two lever distributor kit.
CAUTION
