FERRI ZMT - Guards; Flaps

95
Rev. 5.1
ZMT-ZMTE
EXTRAORDINARY MAINTENANCE
8.4
08-Protezioni (ZMT-ZMTE)
2
3
1
8.5 Guards
Always check the general condition (integrity, xing, etc.) of the guards.
Guards which are deformed, damaged or not xed correctly do not guarantee the working
safety for which they have been designed.
IN THE EVENT OF FAILURE TO COMPLY WITH THE INSTRUCTIONS ABOVE, THE USER
WILL BE CONSIDERED LIABLE FOR ANY AND ALL CIVIL AND/OR CRIMINAL DAMAGE
THAT MAY BE CAUSED.
DANGER
8.5.1 Flaps
At the end of every working day, check the perfect working order of the aps ensuring that they are intact and able
to oscillate.
Clean the machine in the areas covered in mud or dirt, to ensure the mobility of the aps. If necessary, spray them
with lubricating products.
To replace damaged aps, proceed in the following way:
1) undo the xing rod (1) turning the relative nut (2);
2) replace the damaged (3) aps;
3) reassemble the xing rod (1);
