FERRI ZMT - Controls with Distributor; Assembly Procedure

110
ZMT-ZMTE
Rev. 5.1
OPTIONAL UNITS
12.1
12.2
12-Comandi con distributore (ZMT-ZMTE)
1
2
3
1
12.1 Controlswithdistributor
For tractors equipped with only one oil pressure tap or on specic demand by the customer, it is also possible to t a
hydraulic ram control distributor provided with a oat system to control the shredder’s orientation.
12.1.1 Assemblyprocedure
1) Screw or seal the plate (1) to the three-point coupling in the indicated position.
2) Fit the distributor (2) xing it to the plate (1) with the relative fastening screws (3).
