FERRI ZMT - Description of the Parts

34
ZMT-ZMTE
Rev. 5.1
TECHNICAL CHARACTERISTICS
3.2
03-Dati tecnici (ZMT-ZMTE)
1
3
4
5
7
9
10
17
16
2
6
8
11
12
13
14
15
18
3
ZMTE
4
3.3 Description of the parts
1
PTO shaft
11
Flail head orientation hydraulic ram
2
Flail head orientation joint
12
Lateral movement hydraulic ram
3
Gearbox
13
3-point coupling
4
Pulleys
14
Arm support joint
5
Belts
15
Support foot
6
Rear bonnet
16
Lateral movement arms
7
Flail holder shaft
17
Front guard
8
Flails
18
Lateral guard
9
Support roller
19
Shredding ail head
