FERRI ZMT - Adjustable Lateral Rollers

112
ZMT-ZMTE
Rev. 5.1
OPTIONAL UNITS
12.5
12-Slitte laterali regolabili (ZMT-ZMTE)
1
4
4
3
3
2
2
12.2 Adjustablelateralrollers
The application of the rollers (1) allows protection against quick wear to the blades.
They are tted laterally to the side of the shredder with the support of M10 screws (2), washers (3) and nuts (4)
positioned in the way indicated in the gure.
Height adjustment should be carried out simultaneously with the support roller (see Chapter 5).
