2 Product Overview
14 Festo GDCP-CMMS-AS-G2-HW-EN 1310NH English
1 [X9] Power supply
2 [X10] Master/slave ( bi-directional interface)
3 [X1] I/O interface
1
3
2
Fig. 2.3 Top view of CMMS-AS -...-G2
1 [X3] STO interface
2 [X2] Encoder
3 [X6] Motor
4 Shield connection terminal
1
2
3
4
Fig. 2.4 Bottom view of CMMS-AS -...-G2
