Page #17 background imageLoading...
Page #17 background image
2 Product Overview
Festo GDCP-CMMS-AS-G2-HW-EN 1310NH English 17
2.4.4 Slot [EXT]
The slot ( Fig. 2.2 4) enables the CMMS-AS-...-G2 to be expanded by the following optional inter-
faces:
CAMC-PB: Interface for PROFIBUS DP
CAMC-DN: Interface for DeviceNet.
For installation, please observe the assembly instructions for the CAMC interface. If the
interface is installed, it is automatically activated the next time the motor controller is
switched on. Information regarding functionality can be found in the respective fieldbus
manual
PROFIBUS P.BE-CMM-FHPP-PB-SW-...
DeviceNet P.BE-CMMS-F HPP-DN-SW-...
2.4.5 Card s lot [M1] for SD memory card
A parameter set can be loaded from/saved onto the memory card by using the FCT
software. Additional information can be found in the help section for the FCT plug-in
CMMS-AS and in the description GDCP-CMMS-AS-G2-FW-...
SD memory card
Description
Functions Copying/loading a parameter set from the memory card to the
CMMS-AS -...-G2.
Copying/saving a parameter set from the CMMS-AS-...-G2 to the
memory card.
Copying (loading) firmware from the memory card to the
CMMS-AS -...-G2 (Bootloader)
Design on the device 1x12-pin SD c ard slot
Supported card types SD
1)
(version 1 and 2)
Supported file systems FAT16
Format filename 8.3
1) Recommended are industry-suitable memory cards from the Festo accessories programme.
Tab. 2.7 Characteristics of the memory card ( Fig. 2.2 5 )
