B Diagnostic messages
Festo – GDCP-CMMS-AS-G2-HW-EN – 1310NH – English 53
B Diagnostic messages
B.1 Explanations of the diagnostic messages
If an error occurs, the CMMS-A S -...-G2 motor controller shows a warning message c yclically in the
7-segment display. The error message is made up of an E (for Error), a main index and a sub-index, e .g.:
“E 01 0”.
Warnings have the same number as an error message. In contrast to error messages, however, warn-
ings are preceded and followed by hyphens, e.g.: “- 1 7 0 -”
The error tables below contain the following information:
Column
Meaning
No. Main index and sub-index of the diagnostic message.
Code The Code c olumn includes the error code (Hex) via CiA 402.
Message Message that is displayed in the FCT.
Cause Possible causes for the message.
Measure Actio n by the user.
Reaction The Reaction column includes the error response (default setting, partially con-
figurable):
– PS off (switch off output stage)
– QStop (fast stop with parametrised ramp)
–Warn(Warning)
–Ignore(ignore).
Tab. B.1 Explanations for the error tables
The Reaction c olumn includes the error responses of the default parameter set. After
configuration of the motor controller with FCT, the standard values defined in the FCT or
the configured reactions apply.
A complete list of the diagnostic me ssages corresponding to the firmware statuses at the time of print-
ing of this document can be found in section B.2
