A Technical appendix
50 Festo – GDCP-CMMS-AS-G2-HW-EN – 1310NH – English
A.2.7 Motor [X6]
Motor [X6]
Cabling
Thermal rated value [°C] 60/75 class 1
Cable Screened
With integrated filter [m] l ≤ 15
With ferrite core via motor cable
(Ferroxcube TX26/15/20 3C90)
[m] l≤ 25
Cable capacitance of one phase against
screen or between two lines
[pF/m] ≤ 200
Conductor cross-section (plug connector)
Flexible conductor [mm²] 0.25 … 2.5
– Wireendsleevewithout
insulating collar
[mm²] 0.25 … 2.5
– Wireendsleevewith
insulating collar
[mm²] 0.25 … 2.5
Terminal tightening torque [Nm] 0.5 … 0.6
Output data
Output voltage [V AC] 0 … input voltage
Nominal output current I
eff
[A] 4
Peak c urrent [A] 10
Peak c urrent duration
with running motor [s] 2
with stopped motor [s] 0.5
Output frequency [Hz] 1 … 1000
Holding brake
Voltage range [V] 18 … 30
Output current [A] 1A
Voltage loss [V] ≤ 1
Short circuit/overcurrent protection [A] > 4
Temperature protection T
J
[°C] > 150
Load
Ohmic [Ω] > 24
Inductive [H] 10 ( typical)
Capacitive [nF] < 10
Switching delay [ms] < 1
Motor temperature monitoring
Digital sensor (N/C contact)
R
Cold
kΩ < 1
R
Hot
kΩ > 10
Tab. A.12 Connection data: Motor connection [X6]
