A Technical appendix
Festo GDCP-CMMS-AS-G2-HW-EN 1310NH English 51
A.2.8 Power supply [X9]
Power supply [X9]
Cabling
Cable [m] l 2, unshielded
Conductor cross-section (plug connector)
Flexible conductor
Wireendsleevewithout
insulating collar
[mm²] 0.25 2.5
Wireendsleevewith
insulating collar
[mm²] 0.25 2.5
Terminal tightening torque [Nm] 0.5 0.6
Load supply
Input voltage [V AC] 95 250 (single-phase)
Input current [A] 4…5
Rated output (intermediate circuit)
Mounting grid 70 mm
Equipment c learance 10 mm
[W] 600
Mounting grid 140 mm
Equipment c learance 80 mm
[W] 400
Intermediate circuit voltage [V DC] 320
Max. intermediate c ircuit voltage [V DC] 400
End stage power loss [W] 30 35
Own power loss control section [W] 8
Mains frequency [Hz] 50 60
Surge resistance [kV] 4
Logic supply
Nominal voltage [V DC] 24 ± 20 %
Nominal current
Outputs load-f r ee
Without current for holding brake
[A] 0.35
Max. current (incl. holding brake) [A] 1.7
Tab. A.13 Connection data: Power supply [X9]
