B Diagnostic messages
54 Festo – GDCP-CMMS-AS-G2-HW-EN – 1310NH – English
B.2 Diagnostic messages with instructions for trouble-shooting
Error group 01 Internal faults
No. Code Message Reaction
01-0 6180h Stack o verflow PS off
Cause – Incorrect firmware?
– Sporadic high processor load due to special compute-bound
processes (save parameter set, etc.).
Action • Load approved firmware.
• Contact Technical Support.
Error group 02 Intermediate circuit
No. Code Message Reaction
02-0 3220h Undervoltage in intermediate cir cuit Configurable
Cause – Intermediate circuit voltage falls below the parametrised
threshold.
Action • Quick disc harge due to switched-off mains supply.
• Check power supply (mains voltage or mains impedance too
high?).
• Check intermediate circuit voltage (measure).
• Check undervoltage monitor (threshold value).
• Check travel profile: If a motion/travel with lower acceleration
and/or travel speed is possible, then this would result in re-
duced power consumption.
Error group 0 3 T emperature monitoring, motor
No. Code Message Reaction
03-1 4310h Temperature monitoring, motor Configurable
Cause Motor overloaded, temperature too high.
– Motor too hot.
– Sensor defective?
Action • Check paramet ers (current regulator, current limits).
If the error persists when the se nsor is bypassed: device defective.
