2 Product Overview
Festo GDCP-CMMS-AS-G2-HW-EN 1310NH English 13
2.3 Device view
1 LED status display
2 Seven-segment display
3 [S1]: DIP switches for fieldbus settings and
firmware update
4 [EXT]: Slot for optional control interfaces
(PROFIBUS DP, DeviceNet)
5 [M1]: SD- memory card
6 [X4]: CAN-Bus
7 [X5]: RS 232/RS 485
8 Earthing screw (central PE connection)
1
2
3
4
5
6
7
8
Fig. 2.2 Front view of CMMS-AS-...-G2
