A Technical appendix
46 Festo – GDCP-CMMS-AS-G2-HW-EN – 1310NH – English
A.2 Connection data
A.2.1 Mains fuse
Mains fuse
Automatic c ircuit breaker 1-phase
Nominal current 16 A
Characteristic B, slow-blow
Tab. A.3 Connection data: Mains fuse
A.2.2 I/O interface [X1]
I/O interface [X1]
Cable [m] l < 5, recommendation: screened
Digital inputs
Number 14
Nominal voltage [V] 24 (related to 0 V)
Voltage range [V] 19.2 … 28.8
Signal level [V] 0 … 28.8 (PNP logic)
Nominal current [mA] typical: 2.5
maximum: 3
Voltage threshold
High [V] ≥13.1
Low [V] ≤ 3.4
Input impedance [kΩ] 10.5 … 13.5
Reaction time to input [ms] ≤ 5
Reaction time to sample input [μs] ≤ 100
Protective function Against polarity reversal
Digital outputs
Number 4
Signal level [V] 24 (from logic supply)
Nominal current [mA] ≤ 100
Voltage threshold
High [V] > (U
Logic
—1.0)
Low [V] < 0.8
Output reaction time ≤ 3ms
Protective function Against polarity reversal, feedback
Automatic shutdown of the output in the event of
an overload; automatic restar t when the shor t
circuit has been remedied
