B Diagnostic messages
Festo GDCP-CMMS-AS-G2-HW-EN 1310NH English 55
Error group 04 Temperature monitoring, electronics
No. Code Message Reaction
04-0 4210h Over/under temperature of power electronics Configurable
Cause Motor c ontroller is overheated.
Motor controller overloaded?
Temperature display plausible?
Action Check installation conditions, cooling via the housing surface,
the integrated heat sink and backwall.
Check the drive layout (due to possible overloading in
continuous duty).
Error group 05 Internal voltage supply
No. Code Message Reaction
05-0 5114h 5 V electronics su pply fault PS off
Cause Monitoring o f the internal power supply has recognised
undervoltage . This is either due to an internal defect or an
overload/short circuit c aused by connected peripherals.
Action Separate device from the entire peripheral equipment and
check whether the error is still present after reset. If yes, then
there is an internal defect Repair by the ma nufacturer.
05-1 5115h 24 V supply error PS off
Cause Monitoring o f the internal power supply has recognised
undervoltage .
Action Check 24 V logic supply.
S eparate device from the entire peripheral equipment and
check whether the error is still present after reset. If yes, then
there is an internal defect Repair by the ma nufacturer.
05-2 8000h Driver supply error PS off
Cause Error in the plausibility check of the driver supply (Safe Torque Off )
Action Separate device from the entire peripheral equipment and
check whether the error is still present after reset. If yes, then
there is an internal defect Repair by the ma nufacturer.
Error group 06 Intermediate circuit
No. Code Message Reaction
06-0 2320h Over-current of the intermediate circuit/output stage PS off
Cause Motor defective.
Short circuit in the cable.
Output stage de fective.
Action Check motor, cable and motor controller.
