2. Commissioning
2−17
Festo P.BE−CPX−FB13−EN en 0811c
Mod.
no.
Module
Siemens order number
DP identifier
Siemens
DP identifier
EN 50170
Explanation
0 Field bus node
CPX−FB13: DP slave
[status]
64
d
 40
h
, 00
h
Configured with status bits
1 Digital 8−input module
CPX−8DE [8DI]
8DI 10
h
Identifier byte used
completely
2 Digital 8−input module
CPX−8DE [8DI]
8DI 10
h
Identifier byte used
completely
3 Digital 4−output module
CPX−4DA [4DO]x2
8DO 20
h
Only the first 4 bits of the
identifier byte are used
1)
4 Digital multi I/O module
CPX−8DE−8DA [8DI/8DO]
8DX 30
h
Identifier byte used
completely
5 Analogue 2−input module
CPX−2AE−U/I [2AI]
2AI 51
h

6 Analogue 2−output module
CPX−2AA−U/I [2AO]
2AO 61
h

7 VTSA pneumatic interface
(DIL switch set to 1 Ū 8
valve coils)
ISO PlugIn DIL1 [8DO]
8DO 20
h
The pneumatic interface
must be configured
according to the DIL−switch
setting.
1)
As no output module with groupable identifier is used in the subsequent locations,
8 bits are assigned here, but only 4 are used.
Tab.2/11: Configuration for example terminal 2
