2. Commissioning
2−31
Festo P.BE−CPX−FB13−EN en 0811c
Examples of addressing
Addressing example 1: CPX valve terminal with
MPApneumatics
Addresses used as from input/output word 42:
Module no.: 0
12
8DI 4DO 8DI
8 O
I43.0 Ū I43.7
3
O43.0 Ū O43.7
O45.0 Ū O45.3
O45.4 Ū O45.7
Status bits: I42.0 Ū I42.7
8DO
8 O
O42.0 Ū O42.3
1
2345
6
O44.0 Ū O44.7
4 O4 O
1 Field bus node CPX−FB13
2 MPA1 pneumatic modules
3 MPA2 pneumatic modules
Fig.2/9: Addressing the example terminal 1 (see also Fig.2/2)
