2. Commissioning
2−32
Festo P.BE−CPX−FB13−EN en 0811c
Loca
tion
Module DP identifier
Siemens
Input
address
Output
address
0 Field bus node
CPX−FB13: DP slave [status]
64 42 
1 Digital 8−input module
CPX−8DE [8DI]
8DI 43 
2 Digital 4−output module
CPX−4DA [4DO]x2
8DO  42
 MPA pneumatic interface
1)
VMPA−FB−EPL−...
  
3 MPA1 pneumatic module
MPA1S: VMPA1−FB−EMS−8 [8DO]
8DO  43
4 MPA1 pneumatic module
MPA1S: VMPA1−FB−EMS−8 [8DO]
8DO  44
5 MPA2 pneumatic module
MPA2S: VMPA2−FB−EMS−4 [4DO]x2
8DO  45
6 MPA2 pneumatic module
*MPA2S: VMPA2−FB−EMS−4 [4DO]x0
0  (45)
2)
1
) Passive module
2
) Occupies bits 4Ū7 of output byte 45 automatically
Tab.2/15: Input and output addresses for example terminal 1 (see Fig.2/9)
