2. Commissioning
2−33
Festo P.BE−CPX−FB13−EN en 0811c
Addressing example 2: CPX terminal with VTSA pneumatics
Addresses used as from input/output word 42:
12
8DI 8DI 4DO 8DI 2AO
I43.0 ... I43.7
I44.0 ... I44.7
3
O42.0 ... O42.3 O48.0 ... O48.7
I46.0 ... I49.7
O44.0 ... O47.7
Status bits: I42.0 ... I42.7
8DO
Module no.: 0
1
23456
2AI
8 O
7
I45.0 ... I45.7
O43.0 ... O43.7
1 Field bus node CPX−FB13
2 Pneumatic interface
3 VTSA pneumatics
Fig.2/10: Addressing the example terminal 2 (see also Fig.2/3)
