2. Commissioning
2−34
Festo P.BE−CPX−FB13−EN en 0811c
Loca
tion
Module DP identifier
Siemens
Input
address
Output
address
0 Field bus node
CPX−FB13: DP slave [status]
64 42 
1 Digital 8−input module
CPX−8DE [8DI]
8DI 43 
2 Digital 8−input module
CPX−8DE [8DI]
8DI 44 
3 Digital 4−output module
CPX−4DA [4DO]x2
8DO  42
1)
4 Digital multi I/O module
CPX−8DE−8DA [8DI/8DO]
8DX 45 43
5 Analogue 2−input module
CPX−2AE−U/I [2AI]
2AI 46Ū49 
6 Analogue 2−output module
CPX−2AA−U/I [2AO]
2AO  44Ū47
7 VTSA pneumatic interface
ISO PlugIn DIL1 [8DO]
16DO  48
1)
Bit 4 Ū 7 occupied, but not used
Tab.2/16: Input and output addresses for example terminal 2 (see Fig.2/10)
