KelNet Lock - User Guide A0U571B
34
Inputs functions list
N
Function
1
Opening command
Launches an opening procedure (if the lock is not certified).
2
Boltwork switch
This input is activated when the lock is locked.
The Input Unit will display: .
3
Alarm input signal
Input for an alarm signal, for example “Opening, Seismic and Thermal Detection alarm input signal”.
4
G1-Access authorisation
This function is only valid if time “Access authorization (G1) has a value between 15 and 180
seconds.
When the input is deactivated, access is blocked.
When the input is activated (and during 2 minutes after deactivation), access is authorized.
This function is used for an opening procedure or to access to menu from the input unit.
Be careful when using procedure G1: it can block a lock if the G1 authorization command
does not work.
5
G2-Opening without delay
When the input is activated (and during 2 minutes after deactivation), the opening procedure is
done without delay.
6
G3-Opening cancellation
When the input is activated, the current delay is cancelled and the opening is not possible.
7
G4-Delay substitution
When the input is activated (and during 2 minutes after deactivation), the delay before opening is
the substitution delay.
8
Duress remote button
Duress alarm is activated if the remote button is not activated during the delay.
More precisely, the button shall be activated:
o After 5 seconds after the delay starts.
o
Before 5 seconds before the end of the delay.
9
Opening suspension
If the input is activated, at the end of delay:
o The Input Unit displays for this door:
o The bolt return is suspended.
o The second identification is suspended too.
When the input state changes, the opening procedure can restart.
10
No delay – No schedule
When this input is activated, the opening does not take into account schedules, and the delay
before opening is null.
11
Interlocking input
When this input is activated, the opening is forbidden.
By default, all inputs are open.
