A0U571B - KelNet Lock - User Guide 5. SECURE UNIT CONFIGURATION
35
Outputs functions list
N
Functions
1
Bolt fully retracted
This output is activated when the bolt is fully retracted.
2
External alarm management
This output is activated when the bolt is not locked.
This output is used for example inhibit an OSTD alarm.
3
Good identification
This output is activated during 3 seconds after a good identification (open procedure or menu
access).
4
Delay in progress
This output is activated during the delay before opening.
5
End of delay
This output is activated at the end of the delay and:
• During waiting for a second code.
• Or when if there is an open suspension.
• Or during interlocking if this one is activated.
6
Duress alarm
This output is activated after a duress alarm and for a programmable time, by default 3 seconds.
7
Blocked bolt alarm
This output is activated when there is a bolt defect during locking or during unlocking.
8
Door open too long
This output is activated when the door is open for too long.
This time is defined by the parameter “Door opening time” added to time “Alert after door opening
time”.
9
Alarm output signal
This output follows the “Alarm input signal” state except when the bolt moves and when the door is
unlocked.
The output is kept activated during 20 seconds after the “Alarm input signal” disappears.
10
Wrong identification blocking
This output is activated when there are more than 3 false identifications.
The output is deactivated when there is a good identification.
11
Schedule blocking
This output is activated when users are blocked (by schedules or by holidays or by exceptional
closing).
12
Unlock command
= Remote relay function.
This output is activated when the open procedure is done by a user who has the “Right to control
remote output”.
The output is deactivated when the bolt is locked again.
13
Sound alert
This output is activated when the door is open for too long. This time is defined by the parameter
“Door opening time”.
The output is deactivated when the door is closed.
The maximum time of activation is defined by the parameter “Alert after door opening time”.
14
Reserved
15
Power off alarm
This output is activated after power off.
The output is deactivated after the next good identification.
16
Reserved
