110 MS-9050 Series Manual — P/N 52413:F 10/22/2010
Programming Master Programming Level
If ANN-I/O, ANN-LED, or ANN-RLY is the selected module type, the following ANN-BUS Address
Screen will be displayed:
Since the options for each of these module types can be individually set, pressing 2 for Module
Options, while viewing the ANN-BUS Address Screen will display the available options as
described below.
ANN-I/O Options Screen
Pressing 1 while viewing the ANN-I/O Address Screen will program the annunciator module to
annunciate either Point (addressable device address) information or Zone information. Each press
of the 1 key will toggle the display between Zone and Point.
Pressing 2 while viewing the ANN-I/O Address Screen will select the Point range to be annunci-
ated (refer to the tables in “ANN-I/O Zone Option” on page 111 and “ANN-I/O Point Option” on
page 111). If Point has been selected, each press of the 2 key for Range will change the points to be
annunciated with the options being 01 - 30 and 31 - 50.
Note that if Zone has been selected, the 2 key will have no effect since the only zones that can be
annunciated are 00 - 19. The range cannot be changed.
ANN-BUS MODULES
ANN-BUS ADDRESS #
1=TYPE ANN-I/O
2=MODULE OPTIONS
ANN-BUS Address Screen
ANN-I/O ADDR #
1=POINT/ZONE ZONE
2=RANGE 00-19
ACTIVE LEDS ONLY
ANN-I/O Address Screen
