MS-9050 Series Manual — P/N 52413:F 10/22/2010 111
Master Programming Level Programming
ANN-I/O Zone Option
If Zone is selected as the module option, the first ten LED driver outputs on the ANN-I/O module
will display the system status information. The remaining 20 LED driver outputs on the module
will display the active/alarm status of each zone. The LED assignments for the ANN-I/O module
will be as follows.
ANN-I/O Point Option
If Point is selected as the module option, the first ten LED driver outputs on the first ANN-I/O
module will display the system status information. The remaining 30 LED driver outputs on the
first module and 20 LED driver outputs on the second module will be used to display the
active/alarm status of each point in the Point Range programmed for that particular module. The
Module LED Function
1AC Fault
2 Fire Alarm
3 Supervisory
4 Trouble
5 Alarm Silenced
6 Not Used
7 Not Used
8 Not Used
9 Not Used
10 Not Used
11 Zone 00 - Active/Alarm
12 Zone 01 - Active/Alarm
13 Zone 02 - Active/Alarm
14 Zone 03 - Active/Alarm
15 Zone 04 - Active/Alarm
16 Zone 05 - Active/Alarm
17 Zone 06 - Active/Alarm
18 Zone 07 - Active/Alarm
19 Zone 08 - Active/Alarm
20 Zone 09 - Active/Alarm
21 Zone 10 - Active/Alarm
22 Zone 11 - Active/Alarm
23 Zone 12 - Active/Alarm
24 Zone 13 - Active/Alarm
25 Zone 14 - Active/Alarm
26 Zone 15 - Active/Alarm
27 Zone 16 - Active/Alarm
28 Zone 17 - Active/Alarm
29 Zone 18 - Active/Alarm
30 Zone 19 - Active/Alarm
31 Not Used
32 Not Used
33 Not Used
34 Not Used
35 Not Used
36 Not Used
37 Not Used
38 Not Used
39 Not Used
40 Not Used
