Programming Master Programming Level
points that will be annunciated on a particular ANN-I/O module depend on the programming
options selected as far as the device type (detector or module) to be annunciated. The LED assign-
ments for each ANN-I/O module will be as follows.
ANN-I/O Module #1 ANN-I/O Module #2
Module LED Function Function
1 AC Fault Not Used
2 Fire Alarm Not Used
3 Supervisory Not Used
4 Trouble Not Used
5 Alarm Silenced Not Used
6 Not Used Not Used
7 Not Used Not Used
8 Not Used Not Used
9 Not Used Not Used
10 Not Used Not Used
11 Point 01 - Active/Alarm Point 31 - Active/Alarm
12 Point 02 - Active/Alarm Point 32 - Active/Alarm
13 Point 03 - Active/Alarm Point 33 - Active/Alarm
14 Point 04 - Active/Alarm Point 34 - Active/Alarm
15 Point 05 - Active/Alarm Point 35 - Active/Alarm
16 Point 06 - Active/Alarm Point 36 - Active/Alarm
17 Point 07 - Active/Alarm Point 37 - Active/Alarm
18 Point 08 - Active/Alarm Point 38 - Active/Alarm
19 Point 09 - Active/Alarm Point 39 - Active/Alarm
20 Point 10 - Active/Alarm Point 40 - Active/Alarm
21 Point 11 - Active/Alarm Point 41 - Active/Alarm
22 Point 12 - Active/Alarm Point 42 - Active/Alarm
23 Point 13 - Active/Alarm Point 43 - Active/Alarm
24 Point 14 - Active/Alarm Point 44 - Active/Alarm
25 Point 15 - Active/Alarm Point 45 - Active/Alarm
26 Point 16 - Active/Alarm Point 46 - Active/Alarm
27 Point 17 - Active/Alarm Point 47 - Active/Alarm
28 Point 18 - Active/Alarm Point 48 - Active/Alarm
29 Point 19 - Active/Alarm Point 49 - Active/Alarm
30 Point 20 - Active/Alarm Point 50 - Active/Alarm
31 Point 21 - Active/Alarm Not Used
32 Point 22 - Active/Alarm Not Used
33 Point 23 - Active/Alarm Not Used
34 Point 24 - Active/Alarm Not Used
35 Point 25 - Active/Alarm Not Used
36 Point 26 - Active/Alarm Not Used
37 Point 27 - Active/Alarm Not Used
38 Point 28 - Active/Alarm Not Used
39 Point 29 - Active/Alarm Not Used
40 Point 30 - Active/Alarm Not Used
