2.5 Equipment versions
Process connections
The presented connections are used for all models.
Model: 1-channel 2-channel
Pneumatics
Plug connection
CK screw connection
Cutting ring connection
+
+
Channel 1 Channel 2
Fig.2: Process connections
Electrical connections
Two M12 flange connectors are used for the electrical connection.
Connector 1
Connector 2
Model: 1-channel 2-channel
Auxiliary energy
Output signal
Switch outputs
Fig.3: Electrical connections
ATEX Version
earth connection
conductive housing
Fig.4: ATEX Version
