FISCHER PRO-LINE DE90 - Type Plate

2 | Product and functional description FISCHER Mess- und Regeltechnik GmbH
12 BA_EN_DE90
2.5.1 Type plate
The type plates presented here serve to show an example of the information
shown. Some information may not be required depending on the specific device
model.
1 channel version
1
2
3
4
5
6
7
8
10
12
13
14
9
11
15
2 channel version
15 16
1
2
3
4
5
6
7
8
10
9
11
12
14
13
Fig.5: Type plate
1 Conformity 2 Device type (order codes)
3 Basic measuring range 4 Set measuring range
5 Durability 6 Output signal
7 Auxiliary energy 8 Production number
9 Customer item number 10 ATEX marking
11 Special properties 12 Parameter number
13 Circuit diagram 1 14 Circuit diagram 2
15 Data for channel 1 16 Data for channel 2
Explanations of the symbols
Input
Output
Factory Setting
Production No.
Proof Pressure
Customers Art.no.
Parameter No.
CAL
Pmax
P#
M#
Para. #
