5.5.1.1 Mode C1
Directory: \Configuration\Channel 1\Modus K1
Level: 3
\...\...\Mode C1
1 2 3 4
Linear
Flow rate
Table
Volume flow
S
R
U
R
R
Fig.57: Mode C1
In this menu, various modes can be selected for the first measurement channel
(K1). The selected mode is indicated by the option field.
Parameter value Description
Linear Linear input characteristic curve
Flow rate Flow measurements at an orifice plate
Table Level measurements on tanks
Volume flow Volumetric flow measurements in vent-
ilation systems
Linear function Mathematical function
f(x) = mx + b
Back E This represents the output (exit) of the
menu. It takes you back to the Channel
3 menu.
Each of these operating modes requires a different parameterization of the
characteristic curve. After the exit of this menu, the calling menu will supple-
mented by the menu extension Characteristic K1 , which parameterize
the characteristic curve.
The Linear operating mode is an exception. In this case, the menu extension is
not necessary because the parameters are only set in the Measurement
C1 menu.
See also
2 Characteristic curve C1 (menu expansion) [}54]
