FISCHER Mess- und Regeltechnik GmbH Operation | 5
BA_EN_DE90 93
5.7 Service
Directory: \Service
Level: 1
\Service
1 2 3 4
Load configuration
Save configuration
Update firmware
Back
U
E
Fig.136: Service
menu name description
Load configuration The parameterization saved in the
flash memory of the device is loaded.
Save configuration The parameterization is saved in the
flash memory of the device.
USB —▶ configuration A parameterization stored on a USB
stick is loaded.
Configuration —▶ USB The parameterization is stored on a
USB stick.
Update firmware A firmware update stored on a USB
stick is executed.
Back E This represents the output (exit) of the
service menu. It took you 'Back' to the
main menu.
In order to be able to use a USB stick, the housing must first be opened.
DANGER
Opening the housing of ATEX devices
ATEX devices must under no circumstances be opened within the potentially
explosive area.
Lid screw
PH1
Micro USB socket
0.5 Nm
Fig.137: USB port (similar to illustration)
