5.5.3 Channel 3
Directory: \Configuration\Channel 3
Level: 2
\...\Channel 3
1 2 3 4
Mode C3
Measurement C3
Characteristic C3
Number format C3
A
A
U
A
A
Fig.95: Channel 3
The third channel is a 'virtual' channel, which is calculated from the two input
channels 1 and 2 using a mathematical function.
Menu name Description
Mode C3 A With this menu you can select fixed
functions for the measuring channel.
Measurement C3 A In this menu the input of the measuring
channel is parameterized.
Menu expansion
Characteristic C3
This menu is hidden depending on
the selected mode.
A
Number format C3 A In this menu, the decimal places for
the measured value display of the
measuring channel are set.
Colour change C3 A In this menu the color changes for the
measuring channel are parameterized.
Back E This represents the output (exit) of the
menu. This takes you 'Back' to the
configuration menu.
Signpost [►Page]
• Mode C3 [}69]
• Measurement C3 [}69]
• Characteristic C3 [}70]
• Number format C3 [}77]
• Colour change C3 [}77]
