5 Operation
5.1 First steps
5.1.1 Operating modes
Operating mode
After activation, the device automatically starts. The device works according to
its configuration.
Configuration mode
Pressing the button û takes the user from the operating mode to the configur-
ation mode. The device is still operational and works according to its configura-
tion. All parameter changes have a direct effect on how the device operates.
If the device is configured via the USB interface, operation is interrupted when
transmission starts. Operation starts with the new configuration after transmis-
sion. The transfer lasts just a few milliseconds.
5.1.2 Menu tree
Login
Quick access
Configuration
Info
Service
Log in / log out
Timeout
Manage users
Reset passwords
User 1
User 2
User 3
Administrator
User 1 enabled
User 1 password
User 1 permissions
User 2 enabled
User 2 password
User 2 permissions
User 3 enabled
User 3 passw.
User 3 permissions
Admin. password
Language
Designation
Meas.range C1 unit
Meas.range C1 start
Meas.range C1 End
Damping C1
Meas.range C2 unit
Meas.range C2 start
Meas.range C2 end
Damping C2
Menu tree configuration
Device
Version
Input 1
Input 2
Analogue output
Switch output
Modbus RTU
Load configuration
Save configuration
USB —▶ configuration
Configuration —▶ USB
Update firmware
Channel 1
Channel 2
Analogue output
Switch output
Display
Modbus RTU
Channel 3
Fig.30: Menu tree
