FISCHER PRO-LINE DE90 - Baud Rate; Data Format

5 | Operation FISCHER Mess- und Regeltechnik GmbH
90 BA_EN_DE90
5.5.7.1 Baud rate
Directory: \Configuration\Modbus RTU\Baud rate
Level: 3
\...\...\Baud rate
1 2 3 4
2400 baud
4800 baud
9600 baud
14400 baud
S
R
U
R
R
Fig.131: Baud rate
Baud rates Description
2400 Baud Options for data transmission.
4800 Baud
9600 Baud
14400 Baud
19200 Baud
28800 Baud
38400 Baud
56000 Baud
57600 Baud
115200 Baud
Back E This represents the output (exit) of the
menu. Press 'back' to return to the
Modbus RTU menu.
5.5.7.2 Data format
Directory: \Configuration\Modbus RTU\Data format
Level: 3
\...\...\Data format
1 2 3 4
8-N-1
8-N-2
8-O-1
8-O-2
S
R
U
R
R
Fig.132: Data format
Data format Description
8-N-1 8 data-bit – No parity – 1 stop-bit
8-N-2 8 data-bit – No parity – 2 stop-bit
8-O-1 8 data-bit – Odd parity – 1 stop-bit
8-O-2 8 data-bit – Odd parity – 2 stop-bit
8-E-1 8 data-bit – Even parity – 1 stop-bit
8-E-2 8 data-bit – Even parity – 2 stop-bit
Back E This represents the output (exit) of the menu.
Press 'back' to return to the Modbus RTU
menu.
